SIP HG4500 MIG Inverter Welder with SWF 05776

Description KEY FEATURES Integrated control panel with high-quality digital display Separate wire feed mounted on top of the main welder body Infinitely variable power output settings for versatility Comes with interconnecting harness, torch and accessories Heavy-duty all-metal 4-roll wire feed mechanism Technical Information ITEM NO. 05776 Input Supply: 400v (20A) Output Current: 40A – 350A (MIG) 30A – 350A (ARC) Output Voltage: 16v – 31.5v (MIG) 21.6v – 34v (ARC) Voltage Steps: Infinitely variable Duty Cycle: 350A @ 60% (MIG) 350A @ 60% (ARC) Electrode Diameter: Ø 1.6mm – 6mm Wire Diameter: Ø 0.8mm – 1.6mm Wire Spool Size: 5kg – 15kg Protection Level: IP21S Insulation Class: Class H Net Weight: 60.70kg Gross Weight: 75.30kg 15.50kg Product Dimensions: Packaged Dimensions: 810(H) x 945(W) x 495mm(D) 500(H) x 350(W) x 720mm(D)
