Atlas 9OHSC Overhead 9,000 lb. Capacity 2-Post Lift

Features and Benefits: 9,000 lb. Capacity Overhead, Open-Floor Lift Single-Piece Column Design Overall Height: 142″ (11′ 10″) 3-Stage Front Arms/2-Stage Rear Arms Automatic Arm Restraints Single-Point Lock Release Rubber Guards on Carriages Dual Hydraulic Chain-Drive Cylinders Free 12 Piece Truck Adapter Set Mounting Hardware Included Shipping Weight: 1,430 lbs. 5 yr Structural ‐ 2 yr Hydraulic Warranty ‐ Parts Only This part number FREIGHT PREPAID Atlas® ATTD-9OHSC-SS Specifications Capacity9,000 LB. Overall Height 142″ (11′ 10″) Overall Floor Width133 1/2″ (11′ 1 1/2″) Outside Column to Outside Column 125 1/2″ (10′ 5 1/2″) Maximum Lift Height (Without Adapters) 76 3/4″ Maximum Lift Height (With Adapters) 87 3/4″ Minimum Arm Height 4″ Inside Column 109 1/2” (9′ 1 1/2”) Drive Thru 100 1/2” (8′ 4 1/2”) Column Size 8″ x 9 3/8″ Column Thickness of Steel 5mm Base Of Lift 16 3/4″ x 17 3/4″ Motor/Electrical Requirement 220 volt single (1) phase (A 30 amp breaker is recommended) Oil Requirement 3-5 Gallons AW32/AW46 (NOT INCLUDED) Shipping Weight 1,430 LBS. Adapter Heights 4 Each 2”, 3”, 6” Arm Hole/Adapter Peg Size 1.5” Requires a minimum of 4″ of concrete with a 3000 psi. rating Not for use with Diesel Trucks (3/4 ton diesel or larger). Due to the weight placed on the front lifting arms, we recommend customers purchase a 10K or 11K 2-post lift.
